floor standing customized outdoor lcd digital signage

Price: 5000.0~18000.0 USD
Payment Terms: T/T,L/C
Place of Origin: Guangdong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: OD46P01
Production Capacity: 500 Pieces/Month
Delivery Date: within 40 days
Panel Size: 47''
Viewing Angle: 178/178
Brightness: 1500NITS
Input Voltage: 1kw
Protection grade: IP65
Means of Transport: Ocean
Packing: 2160*960*520mm
Brand Name: SENPAL
Max Resolution: 1920*1080
Contrast Ratio: 3000:1
Response Time: 5ms
Environment temperature: -40-55C
Model Number: OD55P01

Professional sun light capable lcd touchscreen information kiosk terminal
1.High brightness:1500nits
2.IP65/NEMA4
3.Ambient light sensor,auto dimmi

 1.Name:floor standing customized outdoor lcd digital signage

outdoor LCD display,LCD advertising display, media player, Totem, Digital signage

2.Product Function:

1. IP65 Outdoor enclosure, waterproof, anti-dust.

2.High brightness, 1500nits, resolution 1920 X1080.

3. Ambient temperature -40 deg C to +55 deg C.

4.6mm AR bonding,TM glass,anti-glare and insulate 99.9% UV,prevent the panel damaged by UV under sunlight.

5. Intelligent air-conditioner, integrated cooling and heating.

6.Adopt patent thermal technology.

7. Ambient light sensor, auto dimming.

8. LCD will not turn black under direct sunlight with 24/7 hours working.

9. Customized design is acceptable. Size 26in-72in.

Specification

Standard Configuration for OD46P01

Display

Panel Size

46"

Aspect Ratio

9:16 Portrait

Resolution

1920*1080 (HD)

Brightness

1500 /2000cd/m²

Contrast Ratio

3000:1

Viewing Angle

178° horizontal / 178° vertical

Display Area

688.4 mm x1217.6mm

Video Interface

VGA HDMI

Audio Interface

AUDIO IN

Brightness Control

Automatically light sensor



Embedded PC

CPU

Intel ATOM D525 Dual Core 1.8G

Memory

2 GB DDR2 800 MHz

Display Card

NVIDIA GT218 512M Independent Video Memory

Hard Disk

250 GB

Interface

12V DC-in, Mic/Audio In, USB 2.0 Port(4), HDMI Port, VGA Conector 10/100/1000 Adaptive Ethernet

Operation

Operating Temperature

-40°C to +55°C

Operating Humidity

5%to100%

Protection Rating

IP65

Power

AC 108-115V,50/60Hz

AC 208-240 V, 50/60 Hz

Power Consumption

1.5 kW (Mainly for AC starting)

All in One Unit

Dimension (WxHxD)

2100 mm x 848 mm x 255 mm (Exclude back haging)

Packing Size

2240mm* 980mm*460mm

Weight

98 kg

Glass

6mmHigh light transmission, anti-reflective, tempered, safe glass

Air Conditioning

1000W Cooling Capacity and 800W Heater

Optional Configuration

1.Touch Function

Infrared Touch or Capacitive Touch

2.Wireless Networks/WIFI

External Wireless Network Interface connecting to PC

3.Remote Info Issue & Management System

Integrated Networks remotely issue contents to display terminal and manage the contents of the display terminal as well

4.Remote Environment Monitoring System

Integrated Networks available for remotely monitoring the inner operating status in the machine

5.Anti Graffiti Protection

Special coating allows easy removal of graffiti without damaging surface

All above information can be adjust according to customer requirement

Application

  • Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy;

    Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnsh-ops;

    Non-    profit Organizations: Telecommunications, post offices, hospital, Houses of Worship ,schools;

    Public Places:subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls;

    stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;

    Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;

    Entertainments: Movie theaters, Casinos, Ski resorts & ski slopes, weatherproof tv enclosure

    fitness halls.
